To increase flexibility and to different control levels: part of the new modular upright
allow a future extension to MCU, 1. Conventional pressure con- configuration and can be speci-
the previously standard pres- trols (Manual pilot regulators fied by the selection of the num-
sure regulators with built-in pilot + pressure gauges) ber of functions to be controlled
59-19177 are now replaced with 2. Pressure Supervision Unit and machine layout. Q
conventional pressure regulators (Manual pilot regulators +
59-27516. Pressure supervision panel)
For large machines with 10 3. MCU (Servo controlled pilot
and 12 sections it is recommend- regulators panel including
ed to supply the air manifolds supervision functions)
from both sides. Then, a sec- Control parts for Pressure
ond pressure regulator (slave) Supervision and Machine Control EMHART GLASS SA
59-90290 must be mounted at Unit are assembled in the FlexIS
the opposite side of 59-27516. 3 machine controller cabinet at Hinterbergstr. 22
the Ware Handling Controller. CH-6312 Steinhausen - Switzerland
Conventional pressure control Tel.:+41-41-7494216
SPECIFICATION E-mail: webmaster@emhartglass.com
Pressure controls can now be panel, Pressure Supervision Unit
specified choosing between three and Machine Control Unit are www.emhartglass.com

Pressure Type of Assy No. of Piping Pressure
Control pressure Type Control panel Functions Assy supervision
Unit control (Option)
200-2255-1 M.C.U LH upright 200-2239-1 6 200-2246-2 N/A
200-2255-2 Manual LH upright 200-2233-2 6 200-2243-6 200-2237-1
200-2255-3 Manual LH upright 200-2233-3 5 200-2243-7 200-2237-1
200-2255-4 Manual LH upright 200-2233-4 4 200-2243-8 200-2237-1
200-2255-5 Manual LH upright 200-2233-5 3 200-2243-9 200-2237-1
200-2255-11 M.C.U. RH upright 200-2239-1 6 200-2246-1 N/A
200-2255-12 Manual RH upright 200-2233-2 6 200-2243-2 200-2237-1
200-2255-13 Manual RH upright 200-2233-3 5 200-2243-3 200-2237-1
200-2255-14 Manual RH upright 200-2233-4 4 200-2243-4 200-2237-1
200-2255-15 Manual RH upright 200-2233-5 3 200-2243-5 200-2237-1
