• Machine performance: 3,600
cycles per hour
• Single indexed motion
• No glass to glass contact
• Tube economizer
• 18 chucks for the main carou-
sel
• Self-centering chucks
• Plug cooling system

Kappa 36-30 for cartridges
• Outer diameter: 8.65 – 12.6
mm (other working range
upon request)
Euromatic project
management • Total length: 35.0 – 95.0 mm
• Product geometry: Dental and
insulin cartridges
TUBE-LOADER • Total length: 28.0 – 100.0 mm • Machine performance: 7,200
Euromatic’s automatic vertical • Product geometry: ISO 8362- cycles per hour
tube loader is suitable to accept 1, ISO 11418-7 and blow back • Single indexed motion
six bundles of glass tube in just • Machine performance: 4,800 • 3 out
1.2 square meters of floor surface. cycles per hour • In-line dimensional control
The Lambda tube loader can • Sequential two-out indexed • Self-centring chucks
be integrated both for index and system • Plug cooling system
continuous forming machine car- • Double indexed motion
ousels. • No glass to glass contact Tau 36 for ampoules
Glass bundles are easily loaded • Tube economizer • Outer diameter: 8.75 – 22.5
in vertical position by an opera- • 36 chucks for the main crown mm (other working range
tor onto the revolving table, • In-line dimensional control by upon request)
this ensures frictionless contact camera • Total length: 60.0 – 160.0 mm
between tubes. • Cooling system for plugs • Product geometry: Din/ISO
The system is provided to • Self-centering chucks and Marzocchi
automatically and gently pick • Machine performance: 7,200
one single tube at a time from Zeta 16-10 for vials cycles per hour
the bundle, thus avoiding pos- • Outer diameter: 10.0 – 32.0 • 36 chucks
sible damage to the tube: glass to mm (other working range • In-line first bottom of a new
glass contact is avoided along the upon request) tube
entire process. • Total length: 27.0 – 100.0 mm • One stem system
A superior PLC structure pro- • Product geometry: ISO 8362- • Solid structure for the main
vides recipes storage and recov- 1, ISO 11418-7 and blow back body
ery for considerable reduction of • Machine performance: 3,000
change format size and start up. cycles per hour AFTER-FORMING
• Single indexed motion WORKING LINE
FORMING MACHINES • No glass to glass contact Euromatic automatic after
Thanks to the decennary-long • Tube economizer forming working lines are suita-
experience in the forming process • 16 chucks for the main carousel ble for connection with any kind
Euromatic proposes an impor- • Self-centering chucks of upstream forming machine:
tant range of different forming • Plug cooling system conveyor line speed is auto-
machines designed and distin- matically synchronized with the
guished by different and special Zeta 18-10 for vials forming machine speed.
features: • Outer diameter: 10.0 – 30.0 All the equipment is CE com-
mm (other working range pliant as standard: guards and
Zeta 098 for vials upon request) doors are safety interlocked and
• Outer diameter: 12.0 – 30.0 • Total length: 27.0 – 100.0 mm the safeguarding system monitors
mm (other working ranges • Product geometry: ISO 8362- the position of a guard or gate,
upon request) 1, ISO 11418-7 and blow back then it is used to shut off power,
