glass without contact with its surface.
Francesca FC machines the only equipment able to carry
out drilling and milling operations completely automatically,
including loading, positioning, setting and unloading.

CHIARA EDGE PROCESSOR

Combiflex
The considerable experience gained with Chiara and Fran-
cesca machines has led to the development of the COMBI-
FLEX island, a stand-alone production line that incorpora-
The Chiara project has revolutionized the grinding sector tes different glass processes within one structure.
thanks to high flexibility this equipment ensures. Chiara can Occupying a space of only 32 sq.m., the Combiflex can pro-
produce 1,000 pieces completely different from each other cess glass up to 1,500x3,000mm with different working fini-
in size, thickness, even out of square, by processing them as shes for each edge. This Forvet proposal is the solution that
all equals. combines limited space and extremely flexible productivity.
The possibility to integrate additional process such as CNC,
CHIARA MULTIFLEX water jet cutting, washing machine, automatic loading and
unloading, after purchase, enables users to modulate their
economic investment with the possibility to implement future
technologies.
With the full configuration, the COMBIFLEX becomes an in-
dependent stand-alone productive island, where the positio-
ning of the rack sheets is the only manual operation required.

Chiara MTP10 MULTIFLEX is designed to produce large
volumes up to 3,300x18,000mm with 10 spindle grinding he-
ads. The integration with a CNC working centre ena-
bles to carry out radii corners, cut outs, milling (also polished)
as well as drilling implementations, without repositioning the
glass. It also allows the production of flat and/or pencil poli-
shed edge finish. The machine can also manage two glasses
(even different from each other) simultaneously.
As the glass flow is in a straight line, the Multiflex
uses a third of the space required for a tra-
ditional double edger machine, for the
same maximum dimensions.

KEY system, CHIARA & FRANCESCA LINE
Loading, scoring, snapping, seaming, grinding, brilliant
polishing, drilling, countersinking, milling, water jet cutting,
washing operations.
ONLY ONE OPERATOR FOR THE WHOLE LINE.
